PUMP
. Stainless steel/Plastic pump body
. Support:cast iron/Aluminum die casting
. Stainless steel impeller
. Max. Liquid temperature:+40℃
. Max Suction:+9m
MOTOR
. Motor with copper winding
. Shaft:Stainless steel welded shaft/45# steel be electroplated
. Insulation class:B or F
. Protection class:IP*4
. Max.Ambient temperature:+40℃
. Cooling:External ventilation
PUMP INSTALLATION AND APPLICATIONS
It can be used to transfer clean water liquids similar to
water in physical and chemical properties.It is suitable for lifting
water form the well,sprinkling irrigation in garden,pressure
boosting of running water,and supporting equipment etc.
